Protect-Fast™ AERO braided sleevingis a tough, lightweight method for protecting cable assemblies, hoses, and wire harnesses from abrasion and cutting while also helping to simplify the installation process. The ECM material is FAR25 approved with low outgassing, is resistant to strong acids and gasoline, and has a temperature rating from -75°C to 125°C.
This AERO sleeving (EDMO# PFAECM3WT1)is constructed with ECTFE copolymer material, is colored white with a black tracer, and has a 1/2 inch diameter. 100 foot mini roll.
规格：
Material:
ECTFE copolymer monofilament
Monofilament Diameter:
0.011 in
Wall Thickness:
0.028 in
Flammability Rating:
UL VW-1
Industry Standard Approvals:
UL 2024 Plenum
NFPA 262 Plenum
FAR 25
FMVSS 302
Expansion:
150% sleeve
Operating Temperature:
-75°C to 150°C (-103°F to 302°F)
Melting Temperature:
250°C (482°F)
Corrosion Resistance:
strong acids, Chlorine, aqueous caustics, gasoline, engine chemicals
Abrasion Resistance:
medium
Recommended Cutting:
with hot knife
Outgassing:
low
特征：
Nominal size: 1/2 inch
Expansion range: 1/4 - 3/4 inch
Mini roll: 100 ft
Color: white with black tracer
Wide operating temperature ranges; melt temperature: 285°C
Resistant to chemicals and corrosion
High and medium abrasion resistance
Low and medium outgassing
