The AV-11 transponder antenna is designed for experimental aircraft, similar to the TED 104-12 antenna. This non-TSO antenna features a BNC connector and has a small mounting footprint. It can operate up to speed of 350 mph and altitude up to 50,000 feet.
规格:
Weight:
1 oz, maximums
Type:
Transponder antenna
Frequency Range:
1030 MHz — 1090 MHz
Impedance:
50Ω
VSWR:
1.3:1, maximum
Polarization:
vertical
Pattern:
Omni-directional
Connector:
BNC female
RF Power Handling:
1 KW peak pulse @ 1% duty cycle
特征:
1030 MHz – 1090 MHz frequency response
Speeds up to 350 mph
Altitudes up to 50,000 feet
